GATE 2025 Question Paper Geology and Geophysics - Geology (GG-1)

GATE
2025
Question Paper | Answer Key
Graduate Aptitude Test in Engineering
(GATE) is a prestigious national-level exam
that assesses candidates for
comprehensive understanding in various
undergraduate-level subjects in
Engineering, Technology, Science,
Architecture, and Humanities.

General Aptitude
Q.1 – Q.5 Carry ONE mark Each

Q.1 Is there any good show _______ television tonight?

Select the most appropriate option to complete the above sentence.

(A) in

(B) at

(C) within

(D) on

Q.2 As the police officer was found guilty of embezzlement, he was _______ dismissed
from the service in accordance with the Service Rules.

Select the most appropriate option to complete the above sentence.

(A) sumptuously

(B) brazenly

(C) unintentionally

(D) summarily

Organizing Institute: IIT Roorkee Page 1 of 39

Q.3 The sum of the following infinite series is:

1 1 1 1 1
+ + + + +⋯
1! 2! 3! 4! 5!

(A) 𝜋

(B) 1+𝑒

(C) 𝑒−1

(D) 𝑒

Q.4 A thin wire is used to construct all the edges of a cube of 1 m side by bending,
cutting and soldering the wire. If the wire is 12 m long, what is the minimum number
of cuts required to construct the wire frame to form the cube?

(A) 3

(B) 4

(C) 6

(D) 12

Organizing Institute: IIT Roorkee Page 2 of 39

Q.5 The figures I, II and III are parts of a sequence. Which one of the following options
comes next in the sequence at IV?

?

I II III IV

(A)

(B)

(C)

(D)

Organizing Institute: IIT Roorkee Page 3 of 39

Q.6 – Q.10 Carry TWO marks Each

Q.6 “Why do they pull down and do away with crooked streets, I wonder, which are my
delight, and hurt no man living? Every day the wealthier nations are pulling down
one or another in their capitals and their great towns: they do not know why they do
it; neither do I. It ought to be enough, surely, to drive the great broad ways which
commerce needs and which are the life-channels of a modern city, without
destroying all history and all the humanity in between: the islands of the past.”

(From Hilaire Belloc’s “The Crooked Streets”)

Based only on the information provided in the above passage, which one of the
following statements is true?

(A) The author of the passage takes delight in wondering.

(B) The wealthier nations are pulling down the crooked streets in their capitals.

(C) In the past, crooked streets were only built on islands.

(D) Great broad ways are needed to protect commerce and history.

Organizing Institute: IIT Roorkee Page 4 of 39

Q.7 Rohit goes to a restaurant for lunch at about 1 PM. When he enters the restaurant,
he notices that the hour and minute hands on the wall clock are exactly coinciding.
After about an hour, when he leaves the restaurant, he notices that the clock hands
are again exactly coinciding. How much time (in minutes) did Rohit spend at the
restaurant?

(A) 6
64 11

(B) 5
66 13

(C) 5
65 11

(D) 6
66 13

Organizing Institute: IIT Roorkee Page 5 of 39

Q.8 A color model is shown in the figure with color codes: Yellow (Y), Magenta (M),
Cyan (Cy), Red (R), Blue (Bl), Green (G), and Black (K).

Which one of the following options displays the color codes that are consistent with
the color model?

(A)

(B)

(C)

(D)

Organizing Institute: IIT Roorkee Page 6 of 39

Q.9 A circle with center at (𝑥, 𝑦) = (0.5, 0) and radius = 0.5 intersects with another
circle with center at (𝑥, 𝑦) = (1, 1) and radius = 1 at two points. One of the points
of intersection (𝑥, 𝑦) is:

(A) (0, 0)

(B) (0.2, 0.4)

(C) (0.5, 0.5)

(D) (1, 2)

Organizing Institute: IIT Roorkee Page 7 of 39

Q.10 An object is said to have an 𝑛-fold rotational symmetry if the object, rotated by an
2𝜋
angle of , is identical to the original.
𝑛

Which one of the following objects exhibits 4-fold rotational symmetry about an
axis perpendicular to the plane of the screen?

Note: The figures shown are representative.

(A)

(B)

(C)

(D)

Organizing Institute: IIT Roorkee Page 8 of 39

PART A: COMPULSORY SECTION FOR ALL CANDIDATES
Q.11– Q .17 Carry ONE mark Each

Q.11 The most volcanically active body in our Solar System is

(A) Mars

(B) Io

(C) Moon

(D) Venus

Q.12 A type of fold which is relatively sharp and angular at its synformal and
antiformal hinges is known as

(A) Fan fold

(B) Drag fold

(C) Chevron fold

(D) Dome

Organizing Institute: IIT Roorkee Page 9 of 39

Q.13 Which one of the following geophysical methods can provide information
on deep Earth structures (of the order of 1000 km) with highest resolution?

(A) Seismic methods

(B) Magnetic methods

(C) Electrical methods

(D) Gravity methods

Q.14 The continuous series of Bowen’s reaction series is represented by

(A) the orthoclase - albite feldspar system

(B) the anorthite - albite system

(C) the forsterite - fayalite system

(D) the diopside - anorthite system

Organizing Institute: IIT Roorkee Page 10 of 39

Q.15 Which of the following time boundaries correspond(s) to major mass extinction
events?

(A) Cretaceous - Paleogene

(B) Paleogene - Neogene

(C) Permian - Triassic

(D) Precambrian - Cambrian

Q.16 A watershed has an area of 74 km2. The stream network within this watershed
consists of three different stream orders. The stream lengths in each order are
as follows:

Ist order streams: 3 km, 2.5 km, 4 km, 3 km, 2 km, 5 km

IInd order streams: 10 km, 15 km, 7 km

IIIrd order streams: 30 km

The drainage density of the watershed is __________ km/km2

(Round off to two decimal places)

Organizing Institute: IIT Roorkee Page 11 of 39

Q.17 A sample contains 7 wt% CaO and 5 wt% MgO. The molar ratio of CaO to MgO
in the sample is ___________

(Round off to two decimal places)

Q.18 – Q .26 Carry TWO marks Each

Q.18 Select the option that lists oxide minerals only.

(A) Spinel, Corundum, Rutile

(B) Olivine, Pyroxene, Magnetite

(C) Apatite, Galena, Monazite

(D) Fluorite, Halite, Calcite

Organizing Institute: IIT Roorkee Page 12 of 39

Q.19 Consider two intersecting, north-easterly striking and south-easterly dipping
dikes Y1 and Y2, which are exposed on an east-west trending vertical wall of
a granite (X) quarry as shown below.

The angle that the dikes make with the horizontal on the quarry wall is

(A) true dip

(B) apparent dip

(C) rake

(D) attitude of foliation

Organizing Institute: IIT Roorkee Page 13 of 39

Q.20 The ratio of P-wave to S-wave velocities, Vp/Vs, within the Earth depends on

(A) bulk modulus

(B) shear modulus

(C) density

(D) coefficient of internal friction

Q.21 Three pixels P, Q, and R in an image are characterized by the NDVI values
of + 0.84, + 0.01, and − 0.89, respectively. Which of the following options
is/are correct?

(A) P is from vegetation area and Q is from barren land

(B) Q is from water body and R is from barren land

(C) Q is from barren land and R is from water body

(D) P is from vegetation area and Q is from water body

Organizing Institute: IIT Roorkee Page 14 of 39

Q.22 Which of the following can indicate the presence of significant
sub-surface iron mineralization?

(A) Free air gravity anomaly

(B) Bouguer gravity anomaly

(C) Magnetic anomaly

(D) Electrical resistivity measurements

Q.23 Which of the following statements is/are correct regarding the magnetic
field lines of the Earth, at the magnetic poles and the magnetic equator?

(A) Horizonal at the equator

(B) Vertical at the poles

(C) Horizonal at the poles

(D) Vertical at the equator

Organizing Institute: IIT Roorkee Page 15 of 39

Q.24 If the lowest Digital Number (DN) value in an image of 10-bit radiometric
resolution is 0, then the maximum DN value of that image is _________

(Answer in integer)

Q.25 If one liter of water at pH 7 is mixed with one liter of water at pH 6, the
resulting pH of the mixture is ____________

(Round off to two decimal places)

Organizing Institute: IIT Roorkee Page 16 of 39

Q.26 A hillslope is shown below. If the area over the failure plane is 50 m2 and the
weight of the hillslope material (W) is 2000 tons, the Factor of Safety (FOS)
for this hillslope in dry conditions is ______________

(Cohesion along failure plane = 196 KPa, dip of failure plane = 60, and internal
friction angle = 30).

(Round off to two decimal places)

Organizing Institute: IIT Roorkee Page 17 of 39

PART B (SECTION 1): FOR GEOLOGY CANDIDATES ONLY
Q.27 – Q.44 Carry ONE mark Each

Q.27 Which one of the following statements explains why elements Li, Be, and B
have low cosmic abundance?

(A) These elements have low masses and hence, they break apart easily

(B) These elements have low binding energies which makes them unstable at
high temperatures at the core of stars

(C) The low abundance of these elements is a unique feature of big stars with
masses greater than 10 times that of our Sun

(D) These elements are highly reactive and hence, unstable

Q.28 During a geochemical exploration survey in a hilly terrain, Cu concentration
of stream sediments from a third order basin outlet was measured to be
3000 ppm. Considering a catchment area of 10 km2 and a Cu background
value of 200 ppm, which one of the following options is the productivity of
this catchment for Cu?

(A) 1.5 × 106 m2

(B) 2.8 × 106 m2

(C) 3.0 ×106 m2

(D) 3.2 × 106 m2

Organizing Institute: IIT Roorkee Page 18 of 39

Q.29 The combinations listed below represent major minerals observed in four
igneous rocks:

(i) Olivine and Anorthite, (ii) K-feldspar and Quartz, (iii) Mg-Ca-pyroxene and
Ca-Na-plagioclase, (iv) Amphibole and Na-Ca-plagioclase

Arrange these mineral combinations based on decreasing temperature of magma
crystallization.

(A) (i) > (ii) > (iii) > (iv)

(B) (i) > (iii) > (iv) > (ii)

(C) (i) > (iv) > (iii) > (ii)

(D) (ii) > (i) > (iv) > (iii)

Organizing Institute: IIT Roorkee Page 19 of 39

Q.30 Shown below is a schematic plot of Nd (deviation of 143Nd/144Nd in a sample
relative to CHUR) versus time. The two solid lines represent the evolution
curves for the depleted mantle reservoir and the continental crust. Which one
of the four dashed lines, marked 1, 2, 3, and 4, represents the evolution of the
CHUR?

(A) Line 1

(B) Line 2

(C) Line 3

(D) Line 4

Organizing Institute: IIT Roorkee Page 20 of 39

Q.31 Which one of the following expressions represents porosity of a rock?

(A) (Solid volume – Pore volume) / Solid volume

(B) (Bulk volume – Pore volume) / Bulk volume

(C) (Bulk volume – Solid volume) / Solid volume

(D) (Bulk volume – Solid volume) / Bulk volume

Q.32 Choose the correct option where both organisms do NOT secrete any CaCO3
(calcite or aragonite).

(A) Foraminifera and Coccolithophore

(B) Diatom and Radiolaria

(C) Diatoms and Corals

(D) Foraminifera and Radiolaria

Organizing Institute: IIT Roorkee Page 21 of 39

Q.33 From the following optical properties of minerals, select an appropriate option
to identify the direction of analyzer and polarizer if the available microscope is
without a cross-hair.

(A) Pleochroism of common hornblende

(B) Extinction of diopside

(C) Extinction of glaucophane

(D) Pleochroism of biotite

Q.34 Which one of the following minerals has crystallographic axes a1 = a2 ≠ c and
all interaxial angles equal to 90?

(A) Beryl

(B) Barite

(C) Plagioclase

(D) Zircon

Organizing Institute: IIT Roorkee Page 22 of 39

Q.35 Which one of the following statements correctly describes the features in the
geological map?

(A) Horizontal sedimentary beds above a basalt basement

(B) Anticline consisting of sedimentary rocks and basalt

(C) Syncline consisting of sedimentary rocks and basalt

(D) Steep south-dipping sedimentary beds above a basalt basement

Organizing Institute: IIT Roorkee Page 23 of 39

Q.36 In which one of the following rivers does helical flow play an important
role in controlling river dynamics and channel morphology?

(A) Meandering rivers

(B) Straight rivers

(C) Braided rivers

(D) Bedrock rivers

Q.37 Which of the following statements is/are NOT correct for stratigraphy of the
Himalaya?

(A) Tethyan Sedimentary Sequence rocks are of Precambrian age

(B) The Lesser Himalayan Sequence rocks are younger than the Higher Himalayan
Crystallines

(C) The Sub-Himalayan Sequence rocks are younger than the Lesser Himalayan
rocks

(D) Collisional Himalayan orogeny occurred in the Cenozoic Era

Organizing Institute: IIT Roorkee Page 24 of 39

Q.38 Which of the following factors will REDUCE the chances of landslide failure?

(A) Increase in shear stress

(B) Increase in water content of pore spaces

(C) Increase in angle of internal friction

(D) Increase in cohesion of soil grains

Q.39 Which of the following rock and texture combinations is/are CORRECT?

(A) Komatiite and Spinifex

(B) Gabbro and Ophitic

(C) Marble and Granoblastic

(D) Basalt and Porphyroblastic

Organizing Institute: IIT Roorkee Page 25 of 39

Q.40 Which of the following statements regarding marine organisms is/are
NOT true?

(A) Foraminifera are multicellular marine organisms

(B) Sponges form their spicules with silica

(C) Coccolithophores are sea-surface dwelling organisms

(D) Species diversity of benthic foraminifera is less than that of planktonic
foraminifera

Q.41 Which of the following rocks is/are characteristic of fossil subduction zones?

(A) Wollastonite and scapolite bearing skarn

(B) Andalusite and staurolite bearing hornfels

(C) Garnet and glaucophane bearing blueschist

(D) Garnet and omphacite bearing eclogite

Organizing Institute: IIT Roorkee Page 26 of 39

Q.42 Compared to Fe, Mg, and Ca, the content of K is extremely low in igneous
clinopyroxene. Which of the following CANNOT explain its low abundance?

(A) K+ has a larger ionic radius than Fe2+, Mg2+ and Ca2+

(B) K is incompatible and hence, enriched in the continental crust

(C) K is fluid mobile and hence, easily leached out of clinopyroxene

(D) K has multiple oxidation states

Q.43 The sediment yield at the outlet of a river having a catchment area of 8 km2
is 6000 tons/year. If the sediment density is 1.5 g/cm3, the average erosion rate
of the river basin is _________________ mm/yr.

(Round off to two decimal places)

Q.44 In a hypothetical rock, the Kd values of element E in minerals M1, M2, and M3
are 1.5, 1.0, and 0.5, respectively. The modal abundances of M1, M2, and M3
are 10%, 40%, and 50%, respectively. The bulk partition coefficient of element
E in this rock is _____________

(Round off to two decimal places)

Organizing Institute: IIT Roorkee Page 27 of 39

Q.45 – Q .65 Carry TWO marks Each

Q.45 A particular Index of Alteration (IA) is defined as the molar concentration ratio
(expressed as weight percentage) of fluid immobile element(s) to fluid mobile
element(s) and is expressed by 100 × ([Al2O3] / {[Al2O3] + [Na2O] + [K2O]}).
For chemical weathering of silicate rocks, which one of the following
statements is correct?

(A) High IA values (> 85) indicate intense chemical weathering

(B) Low IA values (< 15) indicate intense chemical weathering

(C) The IA values do not vary for silicate rocks

(D) The minimum IA value for an unweathered granite is 0

Organizing Institute: IIT Roorkee Page 28 of 39

Q.46 What is the value of the maximum shear stress in a rock, for which the state of
stress is given by the following Mohr circle?

(A) 20 MPa

(B) 40 MPa

(C) 50 MPa

(D) 60 MPa

Organizing Institute: IIT Roorkee Page 29 of 39

Q.47 In a hypothetical scenario, the element Y has 4 stable isotopes 197Y, 198Y, 199Y
and 200Y. The isotope 199Y is radiogenic and is formed by β– decay of the isotope
199
X of the element X with a half-life of 3.51 billion years. An igneous rock,
which has behaved as a closed system, has three different minerals P, Q, and R,
which crystallized from the same magma 2 billion years ago, with initial X/Y
ratios of 1.75, 2.05, and 0.75, respectively. Which one of the following
statements is true for the ratio 199Y/200Y in this igneous rock in the present day?

(A) P>Q>R

(B) R>P>Q

(C) Q>P>R

(D) Q>R>P

Q.48 Which one of the following factors governs the inclination of the slip face
(leeward side) of ripples?

(A) Velocity of the transporting medium

(B) Sediment supply

(C) Internal friction angle

(D) Drag force

Organizing Institute: IIT Roorkee Page 30 of 39

Q.49 High intensity rainfall in the Higher Himalayan region causes extensive damage,
because of its large droplet size. Which one of the following relationships
between the kinetic energy of raindrop (E) and droplet diameter (D) explains this
process?

(A) E  D1/2

(B) E  D2

(C) E  D3

(D) E  D4

Q.50 The units A to H marked on the figure represent different rock formations.
Select the option that describes the chronological sequence from old to young.

(A) F, E, D, G, C, B, A, H

(B) F, E, D, C, B, A, G, H

(C) F, E, D, G, C, H, B, A

(D) F, E, D, H, G, C, B, A

Organizing Institute: IIT Roorkee Page 31 of 39

Q.51 In the IUGS classification diagram for mafic and ultramafic rocks shown below,
choose the correct option for the rocks labelled X and Y.

(A) X: Harzburgite and Y: Olivine Websterite

(B) X: Lherzolite and Y: Olivine Websterite

(C) X: Dunite and Y: Clinopyroxenite

(D) X: Anorthosite and Y: Wehrlite

Organizing Institute: IIT Roorkee Page 32 of 39

Q.52 Choose the correct combination of minerals (listed in Group A) with the
corresponding locations of their deposits (listed in Group B).

Group-A Group-B

M. Magnesite 1. Bikaner

N. Uraninite 2. Nausahi

O. Clay minerals 3. Salem

P. Platinum group elements 4. Jaduguda

(A) M-1; N-2; O-3; P-4

(B) M-4; N-3; O-2; P-1

(C) M-3; N-4; O-1; P-2

(D) M-2; N-4; O-1; P-3

Q.53 Choose the explanation(s) for negative Eu anomalies in upper crustal rocks like
granite and granodiorite.

(A) These rocks are end-products of magmatic differentiation

(B) These rocks were formed by melting of the mantle, which was already
depleted in Eu

(C) Most of the Eu was incorporated in other minerals

(D) The melt residues contain plagioclase which are enriched in Eu

Organizing Institute: IIT Roorkee Page 33 of 39

Q.54 Which characteristic feature(s) best explain(s) the HIMU mantle reservoir?

(A) Magmas derived from this reservoir have high 208Pb/204Pb and 206Pb/204Pb

(B) Magmas derived from this reservoir have high 207Pb/204Pb and 206Pb/204Pb

(C) This reservoir has evolved with high Th/U

(D) This reservoir has evolved with high U/Pb

Q.55 Choose the correct option(s) related to tectonic settings and associated
rock types.

(A) Tholeiitic basalts and alkali basalts are both associated with mid-oceanic ridges

(B) Andesites are commonly found in convergent plate boundaries

(C) Tholeiitic basalts and alkali basalts can both be associated with plume-related
volcanism

(D) Volcanic rocks from subduction zones have high volatile content

Organizing Institute: IIT Roorkee Page 34 of 39

Q.56 Which of the following options is/are correct for movement of warm-base
glaciers?

(A) Movement is dominated by basal sliding

(B) Internal deformation involving slippage within and between ice crystals
leads to glacial movement

(C) Internal deformation is governed by shear stress following Power Law

(D) Vertical profile of glacier flow velocity is maximum at the base and
decreases upwards

Q.57 Choose the correct option(s) that describe(s) the properties of clay minerals.

(A) Kaolinite is two-layered

(B) Illite is two-layered

(C) Montmorillonite is two-layered

(D) Montmorillonite swells in contact with water

Organizing Institute: IIT Roorkee Page 35 of 39

Q.58 Which of the following statements is/are correct for electromagnetic (EM)
radiation?

(A) At room temperature, natural objects emit EM radiation

(B) Blackbody radiation is proportional to square of the absolute temperature
of the body

(C) Wien’s displacement law provides the dominant wavelength of EM emission

(D) EM energy decreases with increase in wavelength

Q.59 Which of the following options can be linked to rise in CO2 concentration in
the atmosphere?

(A) Rise in seawater pH and sea surface temperature

(B) Decrease in seawater pH and increase in bicarbonate ion concentration in
seawater

(C) Warming of surface ocean water and decrease in carbonate ion concentration
in seawater

(D) Decrease in seawater pH and decrease in bicarbonate ion concentration in
seawater

Organizing Institute: IIT Roorkee Page 36 of 39

Q.60 A sediment core of 4 cm diameter and 35.81 cm height was collected. This
core had an initial weight of 1000.00 g and upon drying the sediment, the
weight decreased by 133.75 g. This core has a void ratio of 0.42857, where
void ratio is defined as the ratio of volume of void to the volume of solid
(Vv/Vs). The average density of the sediment in the core is ______ g/cm3.

(Round off to two decimal places)

Q. 61 On a normal fault plane dipping 60 towards east, the measured heave and
throw are 5 m and 12 m, respectively. If the strike-slip component of the fault
is 13 m, the magnitude of true displacement of the fault is ___________ m.

(Round off to one decimal place)

Q.62 In the isochemical phase diagram shown below, the curved arrow represents
the P-T path. The variance at peak metamorphism is __________

(Answer in integer)

Organizing Institute: IIT Roorkee Page 37 of 39

Q.63 A 3×3 image (Image A) has been linearly stretched to get the maximum
contrast in an 8-bit display system. Digital Number (DN) values of the pixels
in Image A are shown. The value of the pixel marked as ‘?’ in the output
Image B after linear stretching is ___________

(Answer in integer)

230
Q.64 Th and 226Ra are intermediate nuclides in the decay series of 238U to 206Pb.
The half-lives of 238U, 230Th, and 226Ra are 4.47 billion years, 75,000 years,
and 1600 years, respectively. At secular equilibrium, when activities are equal,
10 billion atoms of 238U are present. The number of atoms of 226Ra present at
equilibrium is _________

(Answer in integer)

Organizing Institute: IIT Roorkee Page 38 of 39

Q.65 The following table provides the mineral chemistry of a garnet. All oxides
are in weight percentage and cations in atoms per formula unit. Total oxygen
is taken as 12 based on the ideal garnet formula. Consider Fe as Fetotal and
Fe3+ = 0. The Xpyrope of this garnet is ___________

Oxides Wt % Cations apfu
SiO2 39.51 Si 2.998
TiO2 0.05 Ti 0.003
Al2O3 22.35 Al 1.999
Cr2O3 0.00 Cr 0.000
FeO 26.25 Fe 1.666
MnO 0.00 Mn 0.000
MgO 10.80 Mg 1.221
CaO 1.40 Ca 0.114
Na2O 0.00 Na 0.000
K2O 0.00 K 0.000
Total 100.36 Total cation 8.001

(Round off to three decimal places and do not multiply by hundred)

Organizing Institute: IIT Roorkee Page 39 of 39

Entrance Exams
Agricultural Entrance Exams
Architecture Entrance Exam
Arts and Humanities Entrance Exams
Commerce Entrance Examinations
Common Entrance Examinations
Computer Application Entrance Exams
Design Entrance Exams
Education Entrance Exams
Engineering Entrance Exams
Hotel Management Entrance Exams
Law Entrance Exams
MBA Entrance Exams
Media & Journalism Entrance Exams
Medical Entrance Exams
Nursing Entrance Exams
Pharmacy Entrance Exams
Science Entrance Exams
Diploma & Polytechnic
Lateral Entry
