MBOSE Class 12 Question Paper 2024 for Informatics Practices

Meghalaya Board of School Education

QUESTION
PAPERS

Total No. of Printed Pages—12
HS/XII/A.Sc.Com/IP/24

2024

INFORMATICS PRACTICES

Full Marks : 70

Time : 3 hours

The figures in the margin indicate full marks for the questions

General Instructions :

(i) Write all the answers in the Answer Script.

(ii) Attempt multiple choice questions and very short
answer-type questions serially.

(iii) Attempt all parts of a question together at one place.

1. Choose the correct option for the following questions :
1×6=6

(a) Pyplot is an interface of Python’s _____ library.

(i) seaborn

(ii) plotly

(iii) ggplot

(iv) matplotlib

/28 [ P.T.O.

( 2 )

(b) Which of the following is not an aggregate function?

(i) avg()

(ii) sum()

(iii) with()

(iv) min()

(c) Which of the following is not a valid data type in
SQL?

(i) char (n)

(ii) string (n)

(iii) varchar (n)

(iv) float (n)

(d) Which network topology requires a central controller
or hub?

(i) Star

(ii) Bus

(iii) Mesh

(iv) Tree

(e) NIC stands for

(i) Network Information Centre

(ii) Network Interface Card

(iii) Network Integration Card

(iv) Network Integration Centre

HS/XII/A.Sc.Com/IP/24/28 [ Contd.

( 3 )

(f) The legal term to describe the rights of a creator of
original creative or artistic work is called

(i) Copyright

(ii) Copyleft

(iii) GPL

(iv) None of the above

2. Answer the following questions in brief : 1×6=6

(a) For the dataset [125, 92, 87, 65], declare a panda
series having name ‘packets’.

(b) What is a constraint?

(c) Explain SELECT command briefly.

(d) What is the purpose of using router?

(e) How long are digital footprints stored on a server?

(f) What are open source based softwares?

3. Answer the following questions (any three) : 2×3=6

(a) Given a series that stores the area of few States.
Write a code to display the first three largest areas of
State from the series. Given series is created as :
ser1=pd.Series ([34567, 890, 450, 67892, 34677,
78902, 256711]).

HS/XII/A.Sc.Com/IP/24/28 [ P.T.O.

( 4 )

(b) Write code statements for a DataFrame df for the
following :

(i) Delete the column ‘density’ from it

(ii) Delete the row from 3 to 6 from it

(c) What is the difference between ‘iat’ and ‘at’ with
respect to a DataFrame?

(d) What is histogram? How is it useful?

(e) What is data visualization? What is its significance?

4. Answer the following questions (any four) : 2×4=8

(a) Write the output produced by the following SQL
commands :

(i) Select POW(2, 3);

(ii) Select LENGTH(“Informatics Practices”);

(b) In SQL, write the query—

(i) to modify the column Job of table EMPL to have
new width of 30 characters;

(ii) to select all snakes or birds of column species
from the table PET.

(c) What is the default sort order of ORDER BY clause?
What is the use of ORDER BY clause?

HS/XII/A.Sc.Com/IP/24/28 [ Contd.

( 5 )

(d) Predict the output of the following queries :

(i) Select 9 mod 2;

(ii) Select CONCAT(‘catch’, ‘a’, ‘falling’, ‘star’);

(e) What is UPDATE command in SQL? Give one
example.

(f) What is equi-join? Give one example.

5. Answer the following questions (any two) : 2×2=4

(a) What are the two types of modems?

(b) Compare tree and star topology.

(c) Discuss the structure of an email message in brief.

(d) Discuss VoIP protocol.

6. Answer the following questions (any two) : 2×2=4

(a) Why should intellectual property rights be protected?

(b) What is anti-virus software?

(c) What is the need for secure passwords?

(d) Differentiate between active and passive digital foot-
prints.

HS/XII/A.Sc.Com/IP/24/28 [ P.T.O.

( 6 )

7. Answer the following questions : 3×3=9

(a) Write a program to create a DataFrame to store
weight, age and name of 3 people. Print the
DataFrame and transpose the DataFrame.
Or
Write a Python code to create a DataFrame with
appropriate headings from the list given below :
[‘S101’, ‘Amy’, 70], [‘S102’, ‘Bandhi’, 69], [‘S104’,
‘Cathy’, 75], [‘S105’, ‘Gundaho’, 82]

(b) What will be the output of the following?
list1=[100, 98·7, 98·4, 97·7]
list2=[100, 100, 100, 85·4]
index_list=[‘T1’, ‘T2’, ‘T3’, ‘T4’]
a={“column1” : pd.Series (list1, index=index_list),
“column2” : pd.Series (list2, index=index_list)}
df2=pd.DataFrame(a)
print(df2)

Or

Create the following Dataframe allDf and export the
contents of DataFrame to pywork folder of C: drive as
filename ‘all.csv’ :
Name Product Target
Zone A Purba Oven 56000
Zone B Rural Tubewell NAN
Zone C Uttar TV NAN

HS/XII/A.Sc.Com/IP/24/28 [ Contd.

( 7 )

(c) Four sequences are given below :
X=[1, 2, 3, 4]
Y=[10, 20, 25, 30]
A=[0·3, 3·8, 1·5, 2·5]
B=[11, 25, 9, 26]
Write a program to plot them in the same chart as—

(i) a line graph plotted with X and Y with blue color
and having line width as 3;

(ii) a line graph plotted with A and B with triangular
marker of magenta color with linestyle ‘dashed’.

Or

Consider the following codes and figure out what
these are trying to do. The pandas library has been
imported as pd :

(i) pd.read_csv(‘data.csv’, nrows=20)

(ii) pd.read_csv(‘data.csv’, skiprows=[1, 2, 3, 4])

(iii) pd.read_csv(‘data.csv’, header=None)

8. Answer the following questions : 3×3=9

(a) What is SQL? What are the different categories of
commands available in SQL? Explain briefly each
category of commands.

HS/XII/A.Sc.Com/IP/24/28 [ P.T.O.

( 8 )

(b) Explain the following SQL functions with example :

(i) MID()

(ii) NOW()

(iii) COUNT(*)

Or

What is the significance of GROUP BY clause in SQL
query? What is the difference between WHERE
clause and HAVING clause of SQL SELECT
statement?

(c) Write the SQL commands to do the following :

(i) To view the structure of ‘Empl’ table

(ii) To view the existing databases

(iii) To add a column ‘mobile_No’ in the table ‘Empl’

Or

Write suitable SQL queries for the following :

(i) To calculate the exponent for 3 raised to the
power of 4

(ii) To remove all the leading and trailing spaces
from the column user_ID of the table USER

(iii) To convert the email_ID ‘[email protected]’ to
lowercase

HS/XII/A.Sc.Com/IP/24/28 [ Contd.

( 9 )

9. What are the different types of networking/internet-
working devices? 3

Or

What is URL? How is an absolute URL different from a
relative URL?

10. Compare Freeware and Shareware. 3

Or

What is data privacy? Websites that you visit collect what
type of information about you?

11. Answer the following questions : 4×2=8

(a) Find the error in the following code fragments :

(i) S2=pd.Series ([101, 102, 102, 104])
print (S2.index)
S2.index=[0, 1, 2, 3, 4, 5]
S2[5]=220
print (S2)

(ii) S=pd.Series (2, 3, 4, 5, index=range (4))

(iii) S1=pd.Series (1, 2, 3, 4, index=range (7))

(iv) S2=pd.Series ([1, 2, 3, 4], index=range (4))

HS/XII/A.Sc.Com/IP/24/28 [ P.T.O.

( 10 )

Or
Consider the following DataFrame ‘Sales’ containing
yearwise sales figures for five Salespersons in INR.
Here year is column labels and Salesperson name is
row labels :
2014 2015 2016 2017
Madhu 100·5 12000 20000 50000
Kusum 150·8 18000 50000 60000
Kinshuk 200·9 22000 17000 70000
Ankit 30000 30000 35000 80000
Shruti 40000 45000 12500 9000

Write the statements for the following :

(i) Display the sales made by all salesperson in the
year 2017.

(ii) Display the sales made by Shruti in 2016.

(iii) Add the data to Sales for Salesperson Sumeet
where the sales made are [192, 37800, 52000,
74438] in the years [2014, 2015, 2016, 2017]
respectively.

(iv) Delete the data for the year 2014 from the
DataFrame ‘Sales’.

(b) Write a program that reads from a csv file marks.csv
stored in ‘data’ folder of C: drive having data as
‘Name’ and ‘Marks’ in three subjects in a DataFrame.
Then the program should add a column ‘Total’
storing total of marks in three subjects and another
column storing average marks. Print the DataFrame
after adding these columns.

HS/XII/A.Sc.Com/IP/24/28 [ Contd.

( 11 )

Or
Write a program to create a horizontal bar chart from
two data sequences as given below :
means=[20, 35, 30, 35, 27]
stds=[2, 3, 4, 1, 2]
Make sure to show legends.

12. Answer the following questions : 4
Consider the following table FITNESS with details about
fitness products being sold in the store. Write commands
of SQL for (a) to (d) :

Table : FITNESS
PCODE PNAME PRICE MANUFACTURER
P1 Treadmill 21000 Coscore

P2 Bike 20000 Aone

P3 Cross Trainer 14000 Reliable

P4 Multi Gym 34000 Coscore

P5 Massage Chair 5500 Regrosene

P6 Belly Vibrator Belt 6500 Ambawya

(a) To display the names of all the products with price
more than 20000
(b) To display the names of all products by the
manufacturer “Aone”
(c) To change the price data of all the products by
applying 25% discount reduction
(d) To add new row for product with the following
details :
“P7”, “Vibro Exerciser”, “28000”, “Aone”

HS/XII/A.Sc.Com/IP/24/28 [ P.T.O.

( 12 )

Or

Consider the following table GAMES. Write SQL
commands for the following statements :

Table : GAMES

GCode Game Name Type Number Prize Money Schedule Date

101 Carom Board Indoor 2 5000 23-Jan-2004

102 Badminton Outdoor 2 12000 12-Dec-2003

103 Table Tennis Indoor 4 8000 14-Feb-2004

105 Chess Indoor 2 9000 01-Jan-2004

108 Lawn Tennis Outdoor 4 25000 19-Mar-2004

(a) To display the names of all GAMES with their
GCodes

(b) To display details of those GAMES which are having
Prize Money more than 7000

(c) To display the content of the GAMES table in
ascending order of Schedule Date

(d) To display sum of Prize Money for each type of
GAMES

HHH

HS/XII/A.Sc.Com/IP/24/28 24K—760
