BASIC GEOMETRICAL IDEAS
I. Important Concepts/ Result
Point: A point determines a location.

Points are denoted by capital letter. Point P, Point Q etc

Models for point :

 A Line Segment

In geometry, a line segment is a part of a straight line that is bounded by two distinct end points, and contains
every point on the line that is between its end points.

- Here AB is a line segment
- Length of line segment can be
measured
- It is denoted by two capital letters,

 A Line
In geometry, a line is a straight one-dimensional figure that does not have a thickness, and it extends
endlessly in both directions.

- It does not have end points
- It is extended infinitely in both directions
- The length of a line cannot be measured.
- If you extend line segment in both directions endlessly you obtain a line
- Line is denoted by a small letter or two capital letters.

21

 Intersecting Lines :

When two or more lines cross each other in a plane, they are called intersecting lines. The
intersecting lines share a common point, which exists on all the intersecting lines, and is called
the point of intersection.

Here, lines P and Q intersect at point O, which is the point of intersection.

Examples of
intersecting lines:

 Parallel lines :

Lines like these which do not meet are said to be parallel; and are called
parallel lines.
Examples Parallel lines:

22

 Ray :A ray is a portion of a line. It starts at one point (called starting point)
and goes endlessly in a direction.

Examples of Ray:

 Curves: You can draw some of these drawings without lifting the pencil from the paper and without
the use of a ruler. These are all curves

 Polygons

A figure is a polygon if it is a simple closed figure made up entirely of line segments.

 Angles

An angle is made up of two rays starting from a common end point.
The two rays forming the angle are called the arms or sides of the angle.
The common end point is the vertex of the angle.

New information
The word “angle” is derived from the Latin word
“angulus”, which means “corner”.

23

Note: Angle is denoted using one capital letter or three capital letter.

II. Some illustrations/Examples (with solution) preferably of different types.

i) MCQs : 4

Question 1.

Least number of line segments required to make a polygon is

(a) 1(b) 2(c) 3(d) 4

Answer: (c) 3

Question 2.

How many lines can be drawn through given two points?

(a) Only one(b) 2(c) 4(d) Countless
Answer: (a) Only one

Question 3.

How many vertices are there in a triangle?

(a) 1(b) 2(c) 3(c) 4
Answer: (c) 3

Question 4.

Find „False‟ statement.

(a) Two lines intersect in a point(b) The line segment has two end points.

(c) The ray has one initial point.(d) Polygon is a open figure made of line segments only.

Answer: (d) Polygon is a open figure made of line segments only.

ii) Case based study: 1

Using the given figure, name the following:

(a) Line containing point M.

(b) Line passing through four points.

(c) Line passing through three points.

24

(d) Two pairs of intersecting lines.

Solution:

(a) MC is the line containing the point M.(b) AN is the line passing through four points A, B, C and N.

(c) PQ is the line passing through three points P, B and Q.(d) Pairs for intersecting lines are

(i) AN and PQ(ii) AN and MC

iii) Short answer type question:

Question 1.

Draw a rough sketch of:

(a) open curve(b) closed curve

Solution:

Question 2.

Give two examples of line segments and ray from day to day life.

Question 3

Give four examples of intersecting lines from day to day life.

iv) Long answer type questions: 2

Question 1

Explain the following terms: Line segment, Line, Intersecting lines, Parallel lines

Solution:

Line segment: A straight line drawn from any point to any other point is called as line segment.

Line: Line is a straight path of points that goes on forever in two directions. It has infinite length, but no

breadth and height.

Intersecting lines: Interesting lines are lines that pass through the same point.

Parallel lines: Parallel lines are never cross and always stay the same distance apart.

Question 2

In the given figure, l, m and n are three parallel lines, x and y intersect these lines.

25

(i) Name the points lying on the line x.

(ii) Name the points lying on the line y.

(iii) Name the points inside the quadrilateral ABED.

(iv) Name the points outside the quadrilaterals ABED and BCFE.

(v) Name the lines passing through three points.

Solution:

(i) A, B and C lie on the line x.(ii) D, E and F lie on the line y.

(iii) Q is the point inside quadrilateral ABED

(iv) Points R and S are outside the quadrilaterals ABED and BCFE.

(v) Lines x and y pass through the three points A, B, C and D, E, F respectively.

III .Questions for Practice:

i) MCQs :

Question 1.

Least number of line segments required to make a quadrilateral is

(a) 1(b) 2(c) 3(d) 4

Question 2.

How many lines can be drawn through a given point?

(a) Only one(b) 2(c) 4(d) Countless

Question 3.

How many vertices are there in a triangle?

(a) 1(b) 2(c) 3(c) 4

Question 4.
Which of the following has no end points?
(a) Line(b) Ray(c) Line-segment(d) None of these
Question 5.
The number of arms a ray has

26

(A) 1 (B) 0(C) 2 (D) 4
Question 6
If the sum of two angles is greater than 180°, then which of the following is not possible for the two angles?
A) One obtuse angle and one acute angle(B) One reflex angle and one acute angle
(C) Two obtuse angles(D) Two right angles.
Question 7
The number of right angles in a straight angle is
(A) 1 (B) 2(C) 3 (D) 4
Question 8
Find out the incorrect statement, if any, in the following: An angle is formed when we have
(a) two rays with a common end-point(b) two line segments with a common end-point
(c) a ray and a line segment with two common end-point(d) none
Question 9
Which is a mode of perpendicular lines?
(A) letter A (B) letter Z(C) letter O (D) letter L
Question 10
Railway line is an example of
(A) intersecting lines (B) straight lines(C) parallel lines (D) none
ii) Short answer type question
State whether the statements given in questions 1 to 5 are true (T) or false (F):
1. A horizontal line and a vertical line always intersect at right angles.
2. Ray is a polygon3.Two parallel lines meet each other at t point.
4.A ray is a portion of a line. 5.Triangle is a closed curve.

Fill in the blanks from questions 6 to 10

i. An angle greater than 180° and less than a complete angle is called _______.

ii. An angle greater than 90° and less than a 180° angle is called _______.

iii. An angle is made up of two rays starting from a common end point.

iv. The two rays forming the angle are called the __________ of the angle.

v. A line has ______ end points

iii) Long answer type questions

1. Use the figure to name :

(a) Line containing point F.

(b) Line passing through B.

27

(c) Line on which D lies

(d) Two pairs of intersecting lines.

2. Draw three models for intersecting lines

3. Draw three polygons having sides 4, 5 and 6 sides.

4. Draw rough diagrams of two angles such that they have

(a) One point in common.(b) Two points in common.

(c) Three points in common.(d) Four points in common.

5. Draw a rough sketch of a quadrilateral KLMN. State,

(a) two pairs of opposite sides,(b) two pairs of opposite angles,

(c) two pairs of adjacent sides, (d) two pairs of adjacent angles.

6. Illustrate, if possible, each one of the following with a rough diagram: (a) A closed curve that is not a

polygon. (b) An open curve made up entirely of line segments. (c) A polygon with two sides.

28

CLASS TEST-1 M.M. : 20

Multiple Choice Questions (Q 1 to Q 5) 1 × 5 =5

1. How many lines pass through one given point?
a. 1 b. 2 c. countless d. none
2. Which of the following is a model of intersecting lines ?
a. Letter C b. letter X c. letter O d. none
3. Which of the following has to end points?
a. line b. triangle c. line segment d. none
4. The example of intersecting lines
a. X c. O
b. C d. none
5. Pentagon has
a. 3 sides b. 4 sides c. 5 sides d. 6 sides

Say True or False (Q 6 to Q 10) 1 × 5 =5

6. A point indicates a definite position.
7. A line segment is a part of a plane.
8. Two lines in a plane always intersect in a point.
9. Line has two end points.
10. A ray has two arms.
Answer in one word or sentence (Q 11 to Q 14 ) 1 × 4 =4

11. Can we draw a polygon using two line segments? Say Yes or No
12. What is polygon?
13. How many initial points does a ray has ?
14. Name the two rays that form an angle?
Two marks Questions 2×2=4

15. Name the vertex and arms of ∠PQR in the figure.
16. Give two real examples of ray and line segment
17. Write two difference between line and line segment

=================================================================
CLASS TEST-2 M.M.: 30
BASIC GEOMETRICAL IDEAS
Multiple Choice Questions (Q 1 to Q 6) 6×1=6

1. Which of the following has one end point?
(a) Line
(b) Ray
(c) Line-segment
(d) None of these
2. In given fig. PQ is

29

(a) line segment
(b) ray
(c) angle
(d) none
3. Cross –roads is an example of
(a) Parallel lines (c) intersecting lines
(b) Straight lines (d) none
4. How many points does a line have?
a. 1 b. 2 c. countless d. none
5. Two intersecting lines have
a. 1 point common c 2point common
b. No point in common d. none
6. A polygon is a closed figure made of
a. line segment b. line c. ray d. none
Say True or False (Q 7 to Q 12) 6×1=6
7. Two intersecting lines have two points in common.
8. We can count the number of points on the line
9. One can draw polygon using two line segments.
10. An angle is made up of two rays with common initial point.
11. Hexagon is a polygon of seven sides.
12. Sun rays are example of ray
Two marks Questions (Q 13 to Q 17) 5 × 2 = 10
13. Use the figure to name :
(a) Five points(b) A line (c) Four rays
(d) Five line segments

14. Give two examples of parallel lines and intersecting lines.
15. Draw rough diagrams to illustrate the following :
(a) Open curve (b) Closed curve.
16. Draw a rough sketch of ∠ ABC. Mark a point P in its interior and a point
Q in its exterior.
17. Draw parallel lines and write an example of parallel lines.
Four marks Questions (Q 18 to Q 19) 2×4=8
(a) Name the vertices in the figure.
(b) Write the names of seven angles.
(c) Write the names of six line segments.
19. Draw rough diagrams of two angles such that
they have
(a) One point in common.(b) Two points in common.
(c) Three points in common. (d) One ray in common.
=====================================================================

30
