Set 4
MARKING SCHEME
ENGINEERING GRAPHICS

SECTION – A

Q. 1 to Q.14 14×1=14

1. (B) Hidden edges

2. (C) The interior details of a complicated object

3. (D) (iv)

4. (A) (i) and (iv) only

5. (C) (iii)

6. (B) (ii)

7. (B) (iii) only

8. (A) 1-(ii), 2-(i), 3-(iv), 4-(iii)

9. (A) Square thread

10. (C) 30 mm

11. (D) (iii) only

12. (C) Shaft

13. (A) Constraints of manufacturing

14. (B) 1-(ii), 2-(iii), 3-(i), 4-(iv)

68 4

SECTION – B

Q. 15 to Q.18 4×1=4

15. (B) isometric projection and orthographic projection

16. (A) Solids of revolution

17. (B) 420 mm

18. (D) 1540 cm2

Q. 19 to Q.22 4×1=4

19. (D) (iv)

20. (A) represent conventionally the external V-thread

21. (C) Headless screw

22. (B) To prevent the relative motion

23. (a) TURN-BUCKLE (ASSEMBLY):

(i) FRONT VIEW, UPPER HALF IN SECTION (13)

 Drawing the upper half of the body (3)
with hatching lines (1) 4
 Drawing the lower half of the body 3
 Drawing both rods inserting 54 mm in the body with arc
(11/2 x 2=3), conventional representation of threads (1x2=2)
and conventional ends of rods (1/2 x2=1) 6
(ii) RIGHT SIDE VIEW (8)

 Four circles including broken circle 4
 Hatching lines showing conventional end of rod B (1/2) and
cutting plane (1/2) 1
 Hidden lines representing the central portion of the body at a
distance of 44 mm 3

68 5 P.T.O.

Details: (6)

 Printing the title 1
 Scale used 1
 Projection Symbol 1
 Six important dimensions 3

OR
23. (b) SLEEVE AND COTTER JOINT (DIS-ASSEMBLY):

(i) SLEEVE

(a) FRONT VIEW LOWER HALF IN SECTION (8)

 Drawing the boundary of sleeve with rounds of R4 (3) and a
horizontal line in lower half showing a hole of Ø 32 (1) 4
 1
Drawing the cotter holes with taper in the lower half (2 /2),
showing correctness of taper in cotter holes (1/2) as given in the
question 3
 Drawing hatching lines in lower half 1

(b) LEFT SIDE VIEW (6)

 Circle of Ø 52 (2) and circle of Ø 32 (11/2) 31/2
 Both cotter holes 2
 Cutting plane 1
/2

(ii) COTTER – B

(a) FRONT VIEW (4)

 Vertical straight edge (1) and taper edge (1) 2
 Upper and lower horizontal lines with curves 2

(b) LEFT SIDE VIEW (3)

 Two parallel vertical edges 1
 Upper and lower ends of cotter 2

Details: (6)

 Printing the titles of both 1

68 6

 Scale used 1
 Projection Symbol 1
 Six important dimensions 3

SECTION – C
24. (a) ISOMETRIC SCALE : (4)

(i) Drawing lines at an angle of 30O and 45O. 1
(ii) Marking of divisions of 10mm, including divisions of first part of one
mm on true length. 1
(iii) Projections from true length 1:1 to get points on isometric length,
construction of isometric scale. 1
(iv) Printing ‘True length / Scale 1:1’, ‘Isometric length/Isometric scale’
and marking angles of 30O and 45O. 1

24. (b) ISOMETRIC PROJECTION OF TRIANGULAR PRISM: (9)

(i) Drawing helping figure 1
1
(ii) Drawing inverted isometric triangles [front (3) and rear (11/2)] 4 /2
(iii) Drawing horizontal three edges 11/2
(iv) Drawing axis perpendicular to V.P. (1/2) and
direction of viewing (1/2) 1
(v) All Dimensions 1

Note: For incorrect position, (1) mark should be deducted.

25. (a) EXTERNAL METRIC THREAD PROFILE: (8)

(i) Horizontal distances (equal to half of pitch), vertical distances
(D=0.866P, D/8 and D/6) marked correctly. 2
(ii) Drawing of crests (1) and roots (1) of threads (minimum two), flanks
(1) drawn correctly. 3
(iii) Drawing hatching lines with conventional break . 1
(iv) Standard dimensions. 2

Note: If sketched freehand, instead of drawing to scale 1:1, two (2)
marks should be deducted, in all..

68 7 P.T.O.

OR
25. (b) FRONT VIEW OF VERTICAL HEXAGONAL BOLT : (8)

(i) Drawing hexagonal head of the bolt resting on HP (Across the Flat or
across the corner). 3
(ii) Drawing of chamfering arcs. 1
1
(iii) Drawing the threaded (1), unthreaded ( /2) portion and conventional
end (1/2) of the shank. 2
(iv) Standard dimensions. 2

Note: 1. For incorrect position, (1) mark should be deducted.

2. If sketched freehand, instead of drawing to scale 1:1, two (2) marks
should be deducted, in all.
